Module sensor chamber design, easier for maintenance

• Module chamber design: no need to disassemble the whole machine or return it for calibration during maintenance. Simply replace the sensor chamber and it will work properly.
• Adopts a three-key magnetic wand design, enabling on-site maintenance and operation in any explosion-proof area.

ia intrinsically safe explosion-proof circuit design, safe and reliable

• Certified by IECEX, ATEX, and Chinese explosion-proof standards.
• Explosion-proof level: Ex db IIC T6 Gb / Ex db ia IIC T6 Gb / Ex da db ia IIC T6 Gb.
• Protection level: IP66/IP67.

Small size and easier for installation

• Body weight is only 1 kg, easy for one person to install.
• One-person calibration is easily performed using the calibration cap.
• Standard infrared ray controller included for remote settings.
• Quick installation using a mounting plate accessory.
• A wide range of accessories available for industrial applications, including flow cap, duct-mount kit, and pipe-mount kit.
• Factory-calibrated for fast commissioning.

Various data transmission

• Standard 4–20 mA current signal, RS485 Modbus, 1 relay signal output.
• Optional 2 sets of relay signals, voltage 1–5V.
• Optional HART digital communication for configuration.
• Optional wireless transmission modes.
