Multiple operation modes, convenient for use

• 7-inch HD color screen display, easy operation

Modular design supports flexible custom configuration

• Standard RS485 signal input and output, up to 100 gas detectors can be connected
• Support 4~20mA signal input, and can connect 8-32 gas detectors (optional)
• Support 16 channels of 4~20mA signal output (optional)
• Support up to 6 relays, standard 4 relays, with 2 additional relays

Powerful data logging function, convenient for users to view historical data

• Standard SD card to store 1000 alarm events & off-event and 100000 measurement readings
• The storage interval can be set manually
• Support SD card and U disk to export data by one key, which is convenient for users to view or delete records

Multiple display modes can be switched

• Each screen displays 6 channels gas concentration, displays real time date, and real-time curve of the single channel in large font
• Auto-loop and manual loop can be switched between channels
• The device name high and low alarm values can be modified
• Chinese and English language
